NON-WOODY ROOTS


Image Source - TREES, ASSOCIATES, and SHIGO (2 CD set).Non-Woody Roots coming from small woody root.





























Image Source - TREES, ASSOCIATES, and SHIGO (2 CD set).

Non-woody roots on young trees.































A mass of non-woody roots.  The arrows point to grape like structures.  This is a common place to find mycorrhizae in these clumps of living soil.





















Image Source - TREES, ASSOCIATES, and SHIGO (2 CD set).

A cluster of yellow mycorrhizae.  Composite structures made up of non-woody root tissues and fungus.































Image Source - TREES, ASSOCIATES, and SHIGO (2 CD set).

A non-woody root with root hairs.  Root hairs are extensions of single epidermal cells.  Do not confuse them with mycorrhizae which are composite structures.



























Image Source - TREES, ASSOCIATES, and SHIGO (2 CD set).

A mycorrhiza with root hairs and fungus hyphae.
